KTM 300 SX '26

KTM 300 SX '26

The KTM 300 SX is a pure off-road weapon. Lightweight, powerful, and engineered for those who live for the dirt.

Engine

• ⚙️ Type: 1-cylinder, 2-stroke
• 🔧 Displacement: 293.2 cc
• 🔄 Gearbox: 5-speed
• ⛽ Fuel System: KEIHIN EFI, 39mm throttle body
• 💻 EMS: Vitesco Technologies
• 🔧 Clutch: DDS multi-disc wet clutch, Brembo hydraulic
• Primary Drive Ratio: 26:72

Chassis

• 🏏 Frame: 25CrMo4 steel central double cradle
• Rear Subframe: Aluminum-reinforced polyamide
• 🛑 Front Brake: Disc
• 🛑 Rear Brake: Disc
• Chain: 520 non-sealed

Suspension

• Front Fork: WP XACT-USD AER, Ø48mm
• Rear Shock: WP XACT with linkage
• Front Travel: 310 mm
• Rear Travel: 300 mm
• Adjustments: High/low speed compression & rebound

Dimensions & Weight

• Seat Height: 958 mm
• Ground Clearance: 354 mm
• Tank Capacity: 7.2 L
• Weight (dry): 99.4 kg
